Aspect ratio is the ratio of the width of an image to the height of the image. This ratio is expressed as x:y, and differs in case of different images used in photography, television, computer applications and so on. Changing this ratio may distort the images. The resolution of an image is the total number of pixels displayed on your computer or television screen. Generally, the higher the resolution, the higher is the quality of the image.

Comparison chart

Aspect Ratio versus Resolution comparison chart
Edit this comparison chartAspect RatioResolution
Definition Aspect ratio is the ratio of the width of an image to the height of the image (x:y). The resolution of an image is the total number of pixels displayed on your computer or television screen.
About Original aspect ratio (OAR) and Modified aspect ratio (MAR) are the dimensions in which the film is originally produced, or altered to fit a particular screen, respectively. The resolution of digital images can be described as pixel resolution, spatial resolution, spectral resolution, temporal and radiometric resolution.
Commonly used The common aspect ratios used are 1.33:1, 1.37:1, 1.43:1, 1.50:1, 1.56:1, 1.66:1, 1.75:1, 1.78:1, 1.85:1, 2.00:1, 2.20:1, 2.35:1, 2.39:1, 2.55:1 and other ratios. The common monitor resolutions are 640x480, 800x600 and 1024x768.

Types

Original Aspect ratio (OAR) is the aspect ratio in which the film is originally produced. This might be altered to be viewed in other modes, such as television. Converting aspect ratios is possible only by enlarging the original image to filling the area, along with cutting off the excess area, or by stretching the image to fill in the area according to the new ratio.

Modified aspect ratio (MAR) is the aspect ratio assigned in order to fit a type of screen, and different from the dimensions in which it is filmed.

The resolution of digital images can be described as pixel resolution, spatial resolution, spectral resolution, temporal and radiometric resolution.

Pixel resolution defines the number of pixels used in digital imaging. Resolution can be expressed as a horizontal x vertical measurement, in megapixels (horizontal value multiplied by the vertical value, and divided by a million), or per unit area.

Spatial resolution refers to how closely the columns (horizontal value) and rows (vertical value) can be resolved in an image. It not only depends on just the number of pixels but also on the system that creates the image.

Spectral resolution refers to the resolution of different color wavelengths in a coloured image.

Temporal resolution refers to the resolution of events at different time points in movie cameras.

Radiometric resolution is expressed in number of bits and defines the differences in intensity in image files.

Current Standards

The common aspect ratios used are 1.33:1 (35mm silent films, television sets and personal video cameras), 1.37:1 (35mm sound film between 1932 and 1953), 1.43:1 (IMAX format 70 mm wide film), 1.50:1 (used for still photography), 1.56:1 (used in shooting commercials), 1.66:1 (invented by Paramount Pictures), 1.75:1 (used by MGM and Warner Bros. between 1953 and 1955), 1.78:1 (used in high-definition television), 1.85:1 (35mm standard for theatrical film), 2.00:1 (used by American studios in the 1950s), 2.20:1 (70mm standard developed in the 1950s), 2.35:1 (used by Cinemascope and Panavision), 2.39:1 (35mm from 1970 onwards), 2.55:1 (original aspect ratio of Cinemascope), and other ratios.

The common monitor resolutions are 640x480, 800x600 and 1024x768. The other common resolutions used in other media are 350x240 (Video CD), 330x480 (VHS), 440x480 (analog broadcast), 720x480 (DVD), 1280x720 (Blu-ray, HCV), 10000x7000 (IMAX) etc.

Why are Aspect Ratio and Resolution important?

Aspect ratio is important when resizing images or videos so as to avoid distorting them. It is also an important consideration while buying large screen LCDs and Plasma TVs. The aspect ratio for these is 1.78, which is similar to that offered by theaters, and thus attempt to give you the same experience.

Resolution is important when printing high quality images and graphics. More resolution generally means more data and information. Most High definition television and LCD have a fixed-pixel display, and this tells you the amount of detail the monitor can display. A fixed-pixel display always coverts the source material to fit its own resolution.
